TRUSCO Steel Thick Hinge, Plain Finish, Total Length 64mm (10 Pieces) 888-64N 1 Bag

TRUSCO Steel Thick Hinge, Plain Finish, Total Length 64mm (10 Pieces) 888-64N 1 Bag

JAN：4989999095388 　
Architectural hardware Architectural hinges Hardware and building materials Hinge (steel) TRUSCO D hardware
¥563
¥563
Sale Sold out
Shipping calculated at checkout.
Catalog number: 888-64N Specifications: ● Total length (mm): 64 ● Width (mm): 42 ● Thickness (mm): 1.4 ● Number of screw holes: 6 ● Hole diameter (mm): 5.0 ● D2 (mm): 6.2 ● Load capacity (kg) when using 2 pieces: 8 ● Opening angle (°): 300 to 330 degrees ● Surface treatment: Plain finish ● P1 (mm): 26 ● P2 (mm): 50 ● P3 (mm): 25 ● Wood screw diameter x length (mm): 3.1 x 20 ● Surface treatment: Plain finish ● Installation method: Wood screw (sold separately) Material / Finish: ● Steel (SPCC)
View full details
