TRUSCO Stainless Steel Mesh Rack H1228XW1824XD457 4 Tiers TSM-4644 1 Unit

Catalog number: TSM-4644 Features: *Shelf position can be changed in 25mm increments. *Adjuster can be adjusted +15mm for easy leveling. Applications: *Clean rooms, food factories, etc. Specifications: ● Width (mm): 1800 ● Depth (mm): 450 ● Height (mm): 1200 ● Effective width (mm): 1748 ● Pipe diameter (mm): φ25.4 ● Number of shelves (tiers): 4 ● Uniform load capacity (kg/tier): 120 ● External dimensions (mm) Height: 1228 ● External dimensions (mm) Width: 1824 ● Assembly time: 40 minutes per person ● External dimensions Depth (mm): 457 ● Shelf adjustment pitch: 25 mm ● Pipe diameter: φ25.4 mm ● Uniform load capacity: 120 kg/tier ● Maximum load capacity: 1000 kg/unit Material/Finish: ● Body: Stainless steel (SUS304) ● Sleeve: ABS resin Caution: ● Concentrated load reduces the load capacity by half. Be sure to distribute the load evenly when using.
