TRUSCO Hand Tap for Unified Threads, SKS 3/8UNC16 Set T-HT3/8UNC16-S 1 S

Catalog number: T-HT3/8UNC16-S Features: ●Used for making and cleaning screw holes. ●For repairing and making screw threads. Applications: ●Workpiece: Iron, light metals. Specifications: ●Tip: Tip, middle, finish ●Accuracy: JIS Class 3 ●Accuracy notation: JIS Class 3 ●Nominal dimensions: UNC3/8 ●Pitch (mm): 16 ●Thread length (mm): 35 ●Total length (mm): 75 ●Shank diameter (mm): 7 ●Shank square section (mm): 5.5 ●Pilot hole diameter (mm): 8 ●Number of threads: 16 ●Machined thread: Unified thread ●Surface treatment: Non-coated ●Set contents: Tip, middle, top Material/Finish: ●Low alloy steel (SKS) Caution: ●Cannot be used with stainless steel.
