Catalog number: TAG-508N Features: ●For air use only. ●The gun rotates 360°, so the angle can be adjusted according to the location. ●It is possible to continuously discharge grease, so it is ideal for large amounts of grease. ●Grease is for cartridge use only. Uses: ●Greasing machines. Specifications: ●Discharge amount (cc/min): 210 ●Oil tank diameter (mm): 62.6 ●Capacity (cc): 400 ●Total length (mm): 416 ●Maximum pressure (MPa): 24 ●Can use cartridge grease ●Type: Air type ●Nozzle connection screw: R1/8 ●Air pressure used: 0.4 to 0.8 MPa ●Applicable grease: Consistency No. 0, No. 1 Material/Finish: ●Steel ●Zinc alloy ●Aluminum ●PE Set contents/Accessories: ●Nozzle for hydraulic nipple Part number: GHX-3C Caution: ●Make sure that the cartridge grease is firmly attached to the female thread of the main body before using.
