TRUSCO Braided Hose 32X41mm 5m TB-3241-5 1 roll

Catalog number: TB-3241-5 Features: ●Excellent pressure resistance, elasticity, resilience, and bending strength. ●Part numbers are available for fractional lengths (please change the end of the part number to the desired length). Applications: ●Industrial air and water piping for machine tools, molding machines, factory equipment, etc. Specifications: ●Length (m): 5 ●Inner diameter (mm): 32 ●Outer diameter (mm): 41 ●Operating pressure (MPa): 0.5 ●Allowable bending radius (mm or more): 225 ●Operating temperature range (℃): 0 to 60 ●Minimum bending radius (mm): 225 ●Color: Clear Material/Finish: ●Soft polyvinyl chloride resin (PVC) + polyester thread included Caution: ●Do not use in places where the connecting fittings may be subjected to impact or get caught on something (such as floor steps or seams in checkered steel plates). This may cause unexpected accidents such as the connecting fittings flying out. ●When separating the connecting fittings, hold the fittings in your hand. ●After connecting the connecting fittings, gently pull them from both sides to make sure they do not come loose. ●Use couplings designed specifically for blade hoses. Using other couplings may damage the hose.
