TRUSCO Rod End, Oil-Free, Male Thread 12mm, COS12, 1 Box

Catalog number: COS12 Features: ●Oil-free type with synthetic resin with excellent self-lubricating properties bonded to the race surface of the ball. Applications: ●Conveyor machine parts, machine tool parts, FA equipment, packaging, textile, agricultural machinery parts, robot parts. Specifications: ●Shaft diameter (mm): 12 ●Overall width (mm): 32 ●Center distance (mm): 54 ●Overall height (mm): 70 ●Thread dimensions: M12 x 1.75 ●Basic dynamic load rating (kN): 24.00 ●Oil-free type ●Operating temperature range: -30 to 150°C ●Male thread type (right-hand thread) Materials/Finish: ●Body: Steel ●Race: Self-lubricating synthetic resin ●Ball: High carbon chromium bearing steel
