TRUSCO General mild steel welding rod Core diameter 1.6mm Rod length 250mm TSR2-165 1 box

Catalog number: TSR2-165 Features: ● A lime-titania type welding rod containing approximately 30% iron powder in the coating, with excellent re-arc properties and good bead elongation, allowing for welding in all positions, including intermittent welding, fillet welding, and tack welding (temporary welding). Applications: ● For welding thin to thick steel plates. (Thick plates can also be welded by applying multiple layers.) ● For welding general structures such as vehicles, light steel frames, and buildings that use mild steel. Specifications: ●Core diameter (mm): 1.6 ●Rod length (mm): 250 ●Applicable plate thickness (mm): 2.0-4.0 ●Current range (A) downward: 25-45 ●Current range (A) vertical upward/upward: 25-45 ●Approximate number of pieces (pieces): 76 ●Rod end color: red ●JIS standard product ●JIS Z3211 E4303 standard product (lime titania welding rod) Caution: ●Use at excessive current may cause spattering (droplets scattering) and other problems that may lead to poor workability, so please observe the appropriate current range. ●Excessive moisture absorption may cause poor welding workability or pits (holes in the welded area), so please return the welding rod to the package and seal it. ●Can be welded in all positions.
