TRUSCO Relay Terminal Block 600V 35A 8P TOTB-240-8P-FB 1 pc

Catalog number: TOTB-240-8P-FB Features: ●Terminal block for relay connection of electric wires. ●Comes with a one-touch cover. Specifications: ●Color: Black ●Number of poles: 8 ●Length (mm): 119.0 ●Width (mm): 35 ●Height (mm): 24 ●Type: For relay ●Rating: 600V-35A ●Mounting pitch (mm): 12.5 ●Screw size: M4 ●Standard: UL94V-0 ●2-wire connection possible ●Comes with one-touch cover ●Operating temperature range: -40℃ to 90℃ ●Insulation resistance: DC500V 1000MΩ or more ●Withstand voltage (V): AC2500V 1 minute ●Temperature rise: 30℃ or less Material/Finish: ●Body: Polybutylene terephthalate (Flame retardant grade UL94V-0) ●Cover: Polycarbonate (Flame retardant grade UL94V-0)
