TRUSCO Insulated Crimp Sleeve Stranded Wire 1.04-2.63mm 2B Type 20 Pieces T-TGVB-2 1 PK

Catalog number: T-TGVB-2 Features: ●Combined with insulating coating for butting crimp sleeves. Applications: ●Comes with insulating coating for B-type sleeves that butt together wires inserted from both sides of the sleeve for crimping and connecting. Specifications: ●Wire clamping range Stranded wire (mm2): 1.04-2.63 ●Wire clamping range AWG: 16-14 ●Color: Silver ●Total length (mm): 25.5 ●Outer diameter (mm): 3.9 ●Inner dimension (mm): 2.3 ●JIS standard product: × ●L (mm): 25.5 ●R (mm): 15.0 ●D (mm): 3.9 ●d (mm): 2.3 ●B-type ●Compatible tools: Tools for insulated crimp terminals and sleeves Materials/Finish: ●Sleeve: Oxygen-free copper (C1020)/Electrolytic tin plating ●Insulation: PVC
