Catalog number: T-0.3Y-3 Features: ●One side of the mounting hole on the contact surface (tongue) is open, making this a bare crimp terminal that can be installed without completely removing the screw. Applications: ●For connecting soft steel stranded wire or solid wire. Specifications: ●Wire clamping range Stranded wire (mm2): 0.20-0.50 ●Wire clamping range AWG: 24-20 ●External dimension (mm): 5.2 ●Stud diameter (mm): 3.2 ●Total length (mm): 12 ●Inner dimension (mm): 1 ●JIS standard product: × ●Color: Silver ●External dimension (mm): 5.2 ●Open-tip type, single wire compatible type ●Compatible tools: Bare crimp terminal, sleeve tool Material/Finish: ●Terminal: Oxygen-free copper (C1020)/Electrolytic tin plating
