TRUSCO Penetration Terminal Block 300V 12A 2P TOTB-752NS-2P-C-FB 1 piece

Catalog number: TOTB-752NS-2P-C-FB Features: ●Terminal block for through-connecting electric wires. ●Comes with a one-touch cover. Specifications: ●Color: Black ●Number of poles: 2 ●Length (mm): 28.86 ●Width (mm): 13 ●Height (mm): 22.5 ●Type: Through-connection ●Rating: 300V-12A ●Mounting pitch (mm): 7.62 ●Screw size: M3 ●Standard: UL94V-0 ●2-wire connection possible ●Comes with one-touch cover ●Operating temperature range: -40℃ to 90℃ ●Insulation resistance: DC500V 1000MΩ or more ●Withstand voltage (V): AC2500V 1 minute ●Temperature rise: 30℃ or less Material/Finish: ●Body: Polybutylene terephthalate (Flame retardant grade UL94V-0) ●Cover: Polycarbonate (Flame retardant grade UL94V-0)
