TRUSCO Penetration Terminal Block 600V 100A 2P TOTB-358N-2P 1 piece

Catalog number: TOTB-358N-2P Features: ●Terminal block for through-connecting electric wires. ●Comes with a one-touch cover. Specifications: ●Color: Black ●Number of poles: 2 ●Length (mm): 61 ●Width (mm): 30 ●Height (mm): 47.5 ●Type: Through-connection ●Rating: 600V-100A ●Mounting pitch (mm): 16 ●Screw size: M5 ●Standard: UL94V-0 ●2-wire connection possible ●Comes with one-touch cover ●Operating temperature range: -40℃ to 90℃ ●Insulation resistance: DC500V 1000MΩ or more ●Withstand voltage (V): AC2500V 1 minute ●Temperature rise: 30℃ or less Material/Finish: ●Body: Polybutylene terephthalate (Flame retardant grade UL94V-0) ●Cover: Polycarbonate (Flame retardant grade UL94V-0)
