TRUSCO Penetration Terminal Block 600V 156A 3P TOTB-489S-3P 1 piece

Catalog number: TOTB-489S-3P Features: ● Terminal block for through-connecting electric wires. ● Comes with a one-touch cover. Specifications: ● Color: Black ● Number of poles: 3 ● Length (mm): 111 ● Width (mm): 44 ● Height (mm): 70 ● Type: Through-connection ● Rating: 600V-150A ● Mounting pitch (mm): 27 ● Screw size: M8 ● Standard: UL94V-0 ● Can connect 2 wires ● Comes with one-touch cover ● Operating temperature range: -40℃ to 90℃ ● Insulation resistance: DC500V 1000MΩ or more ● Withstand voltage (V): AC2500V 1 minute ● Temperature rise: 30℃ or less Material/Finish: ● Body: Polybutylene terephthalate (Flame retardant grade UL94V-0) ● Cover: Polycarbonate (Flame retardant grade UL94V-0)
