TRUSCO Foot-operated switching valve Port 4 TP-4PA41-8 1 unit

Catalogue number: TP-4PA41-8 Features: ●Compact switching valve with excellent workability. ●Can also be used as a two-way valve. ●Can be used without lubrication. ●To switch, step on for ON and release for OFF. Applications: ●Air directional change. Specifications: ●Effective cross-sectional area (mm2): 6.5 ●Connection diameter IN/OUT: Rc1/4 ●Connection diameter EX: Rc1/8 ●Number of ports: 4 ●Width (mm): 80 ●Depth (mm): 120 ●Height (mm): 48.5 ●Operating pressure (MPa): 0-0.7 ●Operating fluid: Air ●Fluid temperature: 5-60°C
