TRUSCO Electromagnetic Holder Φ50XH50 TMEH-A5 1 unit

Catalog number: TMEH-A5 Features: ●On/off is controlled electrically. ●Used for gripping parts of industrial robots and for suction and transport of processed materials. Applications: ●For gripping parts of various automated equipment and industrial robots. Specifications: ●Suction force (N): 600 ●Height (mm): 50 ●Diameter (mm): 50 ●Voltage (V): DC90 ●Current (A): 0.12 ●Power cord length (m): 0.5 ●Mounting screw hole dimensions: M8 x 1.25 depth 15 ●Power cord length: 0.5m Caution: ●A rectifier is required. ●The electromagnetic holder's specification allowable temperature is 40°C or less for the surrounding area and 50°C or less for the object. ●The maximum suction force varies depending on the material, thickness, and surface finish of the object to be attracted. ●Residual magnetism remains depending on the condition of the object to be attracted. ●Since a strong magnetic field is generated, do not bring it close to precision equipment or other items that may be affected by magnetic force.
