TRUSCO Electromagnetic Holder Φ90XH60 TMEH-A9 1 unit

Catalog number: TMEH-A9 Features: ●Turns on/off by electrical control. ●Used for gripping parts of industrial robots and for suction and transport of processed materials. Applications: ●For gripping parts of various automated equipment and industrial robots. Specifications: ●Suction force (N): 3300 ●Height (mm): 60 ●Diameter (mm): 90 ●Voltage (V): DC90 ●Current (A): 0.35 ●Power cord length (m): 0.5 ●Screw hole dimensions for mounting: M10 x 1.5 depth 15 Caution: ●A rectifier is required. ●The allowable temperature of the electromagnetic holder is 40°C or less for the surrounding area and 50°C or less for the object. ●The maximum suction force varies depending on the material, thickness, and surface finish of the object to be attracted. ●Residual magnetism remains depending on the condition of the object to be attracted. ●Since a strong magnetic field is generated, do not bring it close to precision equipment or other items that may be affected by magnetic force.
