Catalogue number: TP-4P20 Features: ● An easy-to-use 2-port pedal air valve that switches by stepping on it and releasing it to turn it off. ● Can be operated with either hand or foot. ● Can be installed either vertically or horizontally. ● Can be used without lubrication. Specifications: ● Effective cross-sectional area (mm2): 6 ● Connection diameter: Rc1/4 ● Number of ports: 2 ● Width (mm): 60 ● Depth (mm): 36 ● Height (mm): 40.8 ● Operating pressure (MPa): 0.7 ● Fluid used: Air ● Fluid temperature: 5 to 60°C ● Operating pressure: 0.7MPa Material/Finish: ● Body: Aluminum
