TRUSCO E-insert exclusive hand tap upper M3X0.5 EHTP-M3X0.5-3 1 piece

Catalog number: EHTP-M3X0.5-3 Features: ●Tip, middle, and top are sold separately. ●The engagement part is 9 threads for the tip tap, 5 threads for the middle tap, and 1.5 threads for the up tap. ●Hand tap for E-sert only. Applications: ●Workpiece: Soft materials such as aluminum. Specifications: ●Tip: Top ●Accuracy: 1b ●Thread length (mm): 20 ●Total length (mm): 50 ●Shank diameter (mm): 5.0 ●Shank square section (mm): 4.0 ●Pilot hole diameter (mm): 3.1 ●Thread diameter x pitch: M3 x 0.5 ●Accuracy: 1b class Material/Finish: ●SKH Note: ●E-sert is a registered trademark of Tsugami Corporation.
