TRUSCO ER32 collet, gripping diameter: 13.0-14.0mm ER32140 1 piece

Catalog number: ER32140 Features: ● Economy type of 16° taper (DIN6499/ISO15488) collet, which is the world standard. Applications: ● For drilling, end milling, reaming, and tapping. Specifications: ● Grip diameter (mm): 13.0-14.0 ● Outer diameter (mm): 33 ● Total length (mm): 40 ● Standard: ER32 ● 4d tip core runout accuracy: Within 15μm (gripping diameter 1.5-9.9mm), within 20μm (gripping diameter 10.0-26.0mm) ● 16° taper collet (8° on one side), standard in Europe ● DIN6499 ● ISO15488
