TRUSCO M1.5 type shelf caster base unit for D450 CUD-M1.5-445 1 S

Catalog number: CUD-M1.5-445 Features: ●By attaching the caster unit, casters can be attached to the shelves, making it easy to change the layout. Uses: ●Can move various types of storage shelves. Specifications: ●Color: Neo gray ●Caster mounting pitch (mm) free: 71 x 71 ●Caster mounting pitch (mm) fixed: 45 x 80 ●Compatible: For M1.5 type, depth 445 mm ●Compatible models: For M1.5 type, depth 445 mm ●For mounting φ100 mm casters Material/Finish: ●Steel ●Surface treatment: Baked paint Set contents/Accessories: ●2 caster bases ●Bolts and nuts for mounting the main body, M8 x 20, 8 pieces each, M6 x 20 ●Bolts and nuts for mounting the casters, M8 x 20, 16 pieces Note: ●Cannot be installed on shelves with back panels. ●Casters are sold separately. ●When using with casters attached, calculate the load capacity (allowable load of the caster you are using x 4 x 0.8) before use.
