TRUSCO Pless Anchor Hexagonal Head Steel 6X35 Pack of 12 (For Concrete, Blocks, and Wood/Screw-Fixed) PHV-635BT 1 PK

Catalog number: PHV-635BT Features: ● No plug is required, so the pilot hole can be small in diameter. ● Both high and low threads are firmly fixed to the mating material. Applications: ● For concrete, blocks, and wood. ● For wiring and piping saddle fastening. Specifications: ● Nominal diameter d (mm): 6 ● Pilot hole diameter (mm): 5.3 ● Embedded depth (mm): 30 ● Maximum tensile load (kN): 3.4 ● Drilling depth (mm): 45-t ● Length (mm): 35 ● Compatible driver: Hexagonal bit (two-sided width 8 mm) ● Bolt pack included Material/Finish: ● Steel ● Surface treatment: SV (Silver Big) treatment Note: ● Maximum tensile load is the value when the concrete strength is Fc21N/[[MM2]]. ● Drilling depth is the value of length + 10mm-t (attachment thickness).
