Catalog number: T-PTV-20 Features: ● Wiring can be done easily and reliably with just one pair of pliers. ● There is no need to remove the wire coating (stripping) or tape it, and the coated wire can be wired as is. ● Use automotive AV wire and IV wire for the stranded wire. Applications: ● Branch connection. ● For wiring inside equipment. Specifications: ● Color: Blue ● Wire clamping range Solid wire (mm): 1.00-1.6 ● Wire clamping range Stranded wire (mm2): 1.25-2.0 ● Rated current (A): 15 ● Wire clamping range AWG: 16-14 ● Maximum outer diameter of coating (mm): 3.68 ● Rated voltage (V): 600 ● Rated voltage: 600V ● Maximum operating temperature: 105°C Materials/Finish: ● Contact: Brass (C2680)/Electrolytic tin plating ● Insulating cover: Polypropylene (PP)
