TYC SMA Connector Adapter SMA-A-PP(AU) 1 piece

Catalog number: SMA-A-PP(AU) Features: ● SMA connector adapter. Applications: ● SMA relay adapter. ● Stainless steel body with gold plating. ● Plug-plug type. ● It is sometimes used to connect devices together by tightly contacting them, without using cables, with only an adapter. ● Similar names: SMAP-SMAP. Specifications: ● Connector shape: SMA connector ● Characteristic impedance: 50Ω Rated voltage AC: AC 330V Operating frequency range: 12.4GHz Insulation resistance: 5000MΩ or more at DC 500V Withstand voltage: AC 1000V for 1 minute Contact resistance: 4mΩ or less Voltage standing wave ratio: 1.2 or less (0.1 to 12.4GHz) Operating temperature range: -30 to +85℃ Material/Finish: ● Center contact: Brass/gold plating External contact: Stainless steel/gold plating
