ULVAC Pirani Vacuum Gauge (Digital) GP-2001G/WP-01 GP2001G/WP01 1 S

Catalog number: GP2001G/WP01 Features: ● Easy-to-read 4.5-digit digital display on a LED screen. ● Constant-temperature Pirani vacuum gauge that uses the thermal conduction of gas. ● Capable of measuring low vacuum ranges (0.4 to 3000 Pa). ● Durable platinum is used for the filament. ● The probes are interchangeable. ● JCSS calibration is also possible. Applications: ● For low vacuum measurement of analytical equipment and physicochemical equipment. ● For low vacuum measurement of inspection and experimental equipment at universities and research institutes. Specifications: ● Measuring pressure range (Pa): 0.4 to 3000 ● Sensor: WP01 ● Mating flange: φ18 ● Recorder output: 0-10V/linear output ● Measuring pressure range: 0.4Pa to 3000Pa ● Display: Digital, 4.5 digits (LED display) ● Set point: 3 points ● Power supply voltage: AC100-240V/10VA ● External dimensions: 96 x 151 x 48mm (display) Material/Finish: ● Sensor filament - platinum (Pt) Set contents/Accessories: ● Sensor ● Sensor cable 5m ● Detection unit GP-H ● Power cable 3m Note: ● If you wish to export this product outside of Japan, please notify us in advance and be sure to follow the procedures for export control in accordance with the Foreign Exchange and Foreign Trade Control Law and other export control regulations.
