UNIKA Rooty Anchor C Type (Trivalent Chromate) C-1090 C-1090 50 Pieces

Catalogue number: C-1090 Features: ●Simple work of just hammering in the pins ensures reliable installation. ●Just by looking at the pins, you can be sure they have been hammered in completely. Applications: ●Architectural, electrical, sanitation, air conditioning and heating construction, sign and chair installation, machine installation, etc. Specifications: ●Screw size: M10 ●Total length (mm): 90 ●Screw length (mm): 30 ●Maximum thickness of object to be attached (mm): 35 ●Pre-drilled hole diameter (mm): 10.5 ●Maximum tensile load (kN): 14.5 ●Embedded depth (mm): 40 ●Tightening torque (N・m): 35 ●Thickness of object to be attached (mm): 35 ●Total length x screw length x maximum thickness used (mm): 90 x 30 x 35 Material/Finish: ●Steel ●Surface treatment: Trivalent chromate finish
