UNIKA Rooty Anchor C Type (Trivalent Chromate) C-2015 C-2015 10 Pieces

Catalogue number: C-2015 Features: ●Simple work of just hammering in the pins ensures reliable installation. ●Just by looking at the pins, you can be sure that the pins have been hammered in completely. Applications: ●Architectural, electrical, sanitation, heating and cooling construction, sign and chair installation, machine installation, etc. Specifications: ●Screw size: M20 ●Total length (mm): 150 ●Screw length (mm): 50 ●Maximum thickness of object to be attached (mm): 45 ●Pre-drilled hole diameter (mm): 21.5 ●Maximum tensile load (kN): 68.3 ●Embedded depth (mm): 80 ●Tightening torque (N・m): 45 ●Thickness of object to be attached (mm): 45 ●Total length x screw length x maximum thickness used (mm): 150 x 50 x 45 Material/Finish: ●Steel ●Surface treatment: Trivalent chromate finish
