UNIKA Resin A HC-U type (hammer type) HC-12U HC-12U 1 piece

Catalogue number: HC-12U Features: *Bolts and rebar can be cut to length for installation. *The unique glass tube shape reduces the number of hammer blows. *Vinyl ester resin with high alkali resistance is used, allowing long-term storage before installation. Applications: *Foundation work for steel frames, etc. *Road construction. *Tunnel construction. *Installation work for vibrating machinery, etc. Specifications: ●Outer diameter (mm): 13.7 ●Total length (mm): 110 ●Capacity (cm3): 12.0 ●Capacity (ml): 12.0 ●Bolt used (irregular steel bar): M12, W1/2 (D13) ●Drill diameter (irregular steel bar) (mm): 15.0 (16.0) ●Drilling depth (mm): 110 ●Maximum tensile load (kN): 47.2 ●Long-term allowable tensile load (kN): 9.0 ●Short-term allowable tensile load (kN): 13.6 ●Drive-in type Material/Finish: ●Base material: Vinyl ester resin Note: ●The maximum tensile load is the value for bolts (excluding irregular shapes) when the concrete strength FC = 21N/mm2.
