UNIKA Resin A SE type (sealed capsule type) SE-16 SE-16 1 bottle

Catalogue number: SE-16 Features: *An adhesive anchor with excellent earthquake resistance. *Suitable for application to wet base materials. *Uses highly alkali-resistant vinyl ester resin, allowing for long-term storage before application. Applications: *Foundation work for steel frames, etc. *Road construction. *Tunnel construction. *Installation work for vibrating machinery, etc. Specifications: ●Outer diameter (mm): 16.8 ●Total length (mm): 120 ●Capacity (cm3): 21.0 ●Capacity (ml): 21 ●Bolt used (irregular steel bar): M16, W5/8 (D16) ●Drill diameter (irregular steel bar) (mm): 18.0 (20.0) ●Drilling depth (mm): 130 ●Maximum tensile load (kN): 107.6 ●Long-term allowable tensile load (kN): 13.7 ●Short-term allowable tensile load (kN): 27.4 ●Rotational/impact type Material/Finish: ●Main agent: Vinyl ester resin Note: ●The maximum tensile load is the value for the bolt (excluding irregular shapes) when the concrete strength FC = 21N/mm2.
