ユニカ(株)
UNIKA T-Lock TL Type TL-650 TL-650 50 pieces
UNIKA T-Lock TL Type TL-650 TL-650 50 pieces
Regular price
¥6,120
Regular price
Sale price
¥6,120
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Catalogue number: TL-650 Features: ●Since the body diameter and plate width are the same, drilling and anchoring can be done after the equipment is installed. Applications: ●Installation of metal fittings, equipment, and handrails. Specifications: ●Screw size: M6 ●Outer diameter (mm): 7.0 ●Total length (mm): 50 ●Screw length (mm): 33 ●Compatible plate thickness (mm): 10-32 ●Drilled hole diameter (mm): 7.5 ●Plate length (mm): 24 ●Tightening plate thickness (mm): 10-32 ●Required hollow section (mm): 26 ●Maximum tensile load (kN): 3.6 ●Length (mm): 50 ●Boxed Material/Finish: ●Steel
