ユニカ(株)
UNIKA T-Lock TL Type TL-860 TL-860 50 pieces
UNIKA T-Lock TL Type TL-860 TL-860 50 pieces
Regular price
¥6,960
Regular price
Sale price
¥6,960
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Catalogue number: TL-860 Features: ●Since the body diameter and plate width are the same, drilling and anchoring can be done after the equipment is installed. Applications: ●Installation of metal fittings, equipment, and handrails. Specifications: ●Screw size: M8 ●Outer diameter (mm): 8.0 ●Total length (mm): 60 ●Screw length (mm): 40 ●Compatible plate thickness (mm): 12-38 ●Pilot hole diameter (mm): 9.0 ●Plate length (mm): 30 ●Tightening plate thickness (mm): 12-38 ●Required hollow section (mm): 32 ●Maximum tensile load (kN): 4.1 ●Length (mm): 60 ●Boxed Material/Finish: ●Steel
