YAMATO Float type flow meter FS-25-N2 FS-25-N2 1 unit
YAMATO Float type flow meter FS-25-N2 FS-25-N2 1 unit
Regular price
¥9,811
Regular price
Sale price
¥9,811
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Catalog number: FS-25-N2 Features: ●Easy-to-read scale and easy-to-use handle. ●Outlet type flowmeter. ●Available for a wide variety of gases, a wide range of flow rates, and a wide range of options. Applications: ●For pressure regulators and piping installation. Specifications: ●Compatible fluid: Nitrogen [N2] ●Operating pressure (MPa): 0.2 ●Flow rate (L/min): 25 ●Inlet connection: G1/4 male thread ●Outlet connection: Φ8 hose port (M12 x 1 bag nut) ●Accuracy: Full scale ±5% ●Maximum operating pressure: 0.99MPa (conversion required if different from operating pressure) ●Inlet connection: G1/4 male thread Material/Finish: ●Body: Brass
