YOKE Welding Ring 5.4t 8-082-06 1 piece

Catalog number: 8-082-06 Features: ●Ring can be rotated 180 degrees. ●Side lifting and lifting operations are possible. ●Welding block is forged from material with excellent weldability. ●All products undergo magnetic particle inspection before shipping. Applications: ●For moving, carrying, and installing heavy objects such as molds and machine tools. Specifications: ●Basic load capacity (t): 5.4 ●Dimension (mm) A: 85 ●Dimension (mm) B: 20 ​​●Dimension (mm) C: 39 ●Dimension (mm) D: 60 ●Dimension (mm) E: 89 ●Dimension (mm) F: 91 ●Dimension (mm) L: 171 ●Dimension (mm) M: 98 ●Dimension (mm) HV: 5 ●Dimension (mm) a: 3 ●Complies with EN1677-1 ●DGUV GS-OA-15-04 certified ●Complies with REACH regulations Materials/Finish: ●Body: Forged alloy steel, Welded parts: S355J2+N
