YOKE Welding Ring 8t 8-082-10 1 pc

Catalog number: 8-082-10 Features: ●Ring can be rotated 180 degrees. ●Side lifting and lifting operations are possible. ●Welding block is forged from material with excellent weldability. ●All products undergo magnetic particle inspection before shipping. Applications: ●For moving, carrying, and installing heavy objects such as molds and machine tools. Specifications: ●Basic load capacity (t): 8 ●Dimension (mm) A: 95 ●Dimension (mm) B: 21 ●Dimension (mm) C: 46 ●Dimension (mm) D: 65 ●Dimension (mm) E: 100 ●Dimension (mm) F: 100 ●Dimension (mm) L: 196 ●Dimension (mm) M: 106 ●Dimension (mm) HV: 7 ●Dimension (mm) a: 4 ●Complies with EN1677-1 ●DGUV GS-OA-15-04 certified ●Complies with REACH regulations Materials/Finish: ●Body: Forged alloy steel, Welded parts: S355J2+N
