Catalog number: 400-15A Features: ● Sight glass that allows you to check the flow by rotating the spinner. ● The installation direction of the piping (horizontal or vertical) is optional. Applications: ● Applicable fluid: cold and hot water. Specifications: ● Nominal diameter A: 15 ● Nominal diameter B: 1/2 ● Total length (mm): 76 ● Connection method: JIS Rc ● Maximum operating pressure: 0.7MPa ● Maximum operating temperature: 100℃ ● Heat shock resistance temperature: 40℃ Materials/Finish: ● Body: Bronze ● Glass: Hard glass
