(200140585) Adjuster AD-501-120E 1 piece

The height can be adjusted with a screwdriver using the cross recess (M8 specification) on the top of the threaded part. There are also optional covers (ADKW and ADKB) that can be attached to the bottom to prevent damage to the floor. We also accept orders for custom specifications such as surface and dimensions. For measuring instruments and steel cabinets. For various cabinets and devices. Allowable load (kgf): 100 Screw size: M8 Thread length (mm): 113 Overall height (mm): 120 Base diameter (mm): 30 Color: Silver Width(mm):30 Height (mm): 120 d(mm): M8 Threaded section top surface: Cross recess H(mm): 120 Load capacity (N): 980 Cross recess Cover sold separately: ADKW, ADKB Material/Finish: Screw/Steel (SWCH), Pedestal/Steel (SPHC) Country of Origin: Japan Code number: 158-1880
